DESCRIPTION

Basic Info

Model NO.	XC-LF5A
Cooling Method	Air-cooled
Selected Voltage	380V/50HZ
Compressor Number	1
Noise Level	Low
Application Fields	Plastic
Certification	ISO, CE
Condition	New
Rated Powder	5HP
Cooling Capacity	12758kcal/H
Working Temperature	3~50 Degree
Refrigerant Type	R22
Evaporator	Shell and Tube
Condenser	Finned Copper Tube+Low Noise Outer Rotor Fan
Transport Package	Wooden Case as Usual
Specification	1280x680x1225 mm
Trademark	XIECHENG
Origin	China

Packaging & Delivery

Package size per unit product 128.00cm * 68.00cm * 122.50cm Gross weight per unit product 227.000kg

Product Description

Xiecheng R22/R407c 5HP Low Temp Compressor Industrial Water Chiller Machine Air Cooled Chiller

Product Description

Air Cooled Water Chiller

Industrial chillers are widely used in plastics, electronics manufacturing, electroplating, pharmaceutical and chemical, ultrasonic cooling, printing and other industrial productions. It can precisely control the temperature required for modern industrial manufacturing and largely improve efficiency and product quality. It is the best choice for modern industries with simple operation, reasonable design and superior quality and over one hundred different models.

Suitable for various industries

Industrial water chiller is to provide a cooling process in plastic molding, to improve quality of molded products and shorten period of injection molding cycles. Hence maximizes productivity of plastic molding manufacturing.

Product Specifications

Model		Unit	XC-LF1A	XC-LF2A	XC-LF3A	XC-LF5A	XC-LF6A	XC-LF8A	XC-LF10A
Cooling Capacity		KW	2.77	5.28	7.91	14.5	17.5	27	35
		Kcal/h	2382	4541	6803	12759	15054	23220	30100
Compressor	Input Power	KW	0.75	1.5	2.2	3.75	4.5	6	3.75x2
	Rated Power	HP	1	2	3	5	6	8	10
Power			1PH-220V/50HZ		3PH-380V/50HZ(200V/220V/415V 50HZ/60HZ)
Evaporator	Type		Water tank coil type			Shell and tube
	Pipe Diameter	inch	1''	1''	1''	1''	1''	2''	2''
Refrigerant	Type		R22
	Quantity	KG	1.6	1.8	2	2	2.5	4	5
Condenser (water chiller)	Type		Shell and tube condenser
	Pipe Diameter	inch			1''	1''	1''	1.5''	1.5''
Cooling Water Flow		m³/h	0.476	0.908	1.36	2.22	2.6	3.95	4.42
Condenser (air chiller)	Type		High efficiency copper tube sleeve aluminum fin type + low noise outer rotor fan
	Fan Power	KW	90x1	170x1	180x1	180x2	180x2	420x2	420x2
Water Tank Capacity		Liter	20	25	40	45	45	80	80
Pump	Power	KW	0.37	0.37	0.37	0.75	0.75	1.5	1.5
		HP	0.5	0.5	0.5	1	1	2	2
	Distance	m	23	23	23	35	35	15	15
	Flow Rate	L/min	100	100	100	110	110	360	360
Safety Protection		Compressor overheat protection, overcurrent protection, high and low pressure protection, over temperature protection, flow protection, phase sequence/phase loss protection, exhaust overheat protection, antifreeze protection
Dimensions		mm	800*490*865	800*565*1025	960*630*1025	1280*680*1225	1280*680*1225	1550*850*1508	1550*850*1508

If you want more sizes, please contact us for details

CONTACT SUPPLIER

Product Actual Shooting

Product Details

01 Microcomputer LCD Controller

▪ Simultaneously displays the cold water outlet and the set temperature;▪ Easy to operate with accuracy of controlling water temperature within 3ºC to 50ºC.

02 Famous Band Compressors

Using famous brand Copeland compressor, with lower noise and less vibration, efficient and energy saving.

03 Shell&Tube Evaporators

Shell and tube evaporator adopts high-precision internal threaded copper tube design with larger heat exchanging area for higher efficiency and maximizing system performance.

04 V Type Finned condensers

With high efficient fin type condenser and silent refrigeration fan, no need to equip cooling water, easy to install.

05 Water Pump

Advanced stainless steel Oakland water pump, with large working range, low noise, reliable performance and no leakage and maintenance-free.

Application Range

The chiller is used in the plastic processing machinery mold cooling, electroplating industry,machinery industry, building industry, vacuum coating and food industry,etc.
